ICON 2010-2014 Ford F-150 SVT Raptor Rear ICON Leaf Spring Hardware Kit

The ICON Vehicle Dynamics Leaf Spring Hardware Kit provides all of the essential components required for installation of ICON 198501 Multi-Rate Leaf Springs on 2010-2014 Ford F-150 Raptor models. The kit includes durable black E-coated U-bolts and heavy-duty U-bolt plates to securely fasten the leaf springs, while precision billet aluminum bump stop spacers allow the factory rear bump stops to be retained after eliminating the OE lift blocks. New front leaf spring mounting bolts are also included to replace the factory hardware that must be cut during removal of the original leaf springs. Engineered for a straightforward installation using high-quality components, this hardware kit ensures a secure fit and reliable performance for your ICON rear suspension upgrade.

• Essential hardware for use with ICON 198501 Multi-Rate Leaf Springs
• Black E-coated U-bolts with U-bolt plates
• Billet aluminum bump stop spacers allow OE bump stops to be used with elimination of factory blocks
• Front mounting bolts replace those cut upon remove of OE leaf springs

Vehicle Specific

• ICON 10-14 RAPTOR LEAF SPRING HARDWARE KIT

Attributes:

• Brand Name: ICON Vehicle Dynamics
• GTIN: 00840103409023
• 10: Steel
• 17: Black
• 1908: 8
• 3078: 4
• 3115: Yes
• 3145: Specific
• 3390: Performance
• 4756: 9
• 4757: 3.125
• AAP_UDA_12: EA
• AAP_UDA_22: 1
• AAP_UDA_4: 55
• California Prop 65 Warning: Yes
• Thread Diameter: 0.625
• Thread Size: 5/8 - 18

Extended Information:

• Country of Origin: United States
• Emissions : Emissions Compliance Exempt

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 10.0000 x 10.0000 x 4.0000 inches
• Weight: 13.0000 POUNDS
