18-UP JL/20-UP JT 2.0 CENTERLINE STABILIZER KIT

Engineered to provide consistent steering damping with a through-shaft design, the ICON Centerline Steering Stabilizer eliminates the common push/pull sensation associated with traditional steering stabilizers. Developed with a wide range of aftermarket Jeep components in mind, this stabilizer features a high clearance design that allows for fitment on all ICON suspension systems. This new Centerline Steering Stabilizer shares the same great build features as our proven ICON 2.0 Aluminum Series shocks. These features include a clear anodized 6063 aluminum shock body for corrosion resistance and a 5/8” chrome plated hardened steel shaft for durability, premium 5WT shock oil that provides consistent damping characteristics across a wide operating temperature range, and a high temperature long wear seal pack that stands up to harsh conditions found both on and off-road. The Centerline Stabilizer mounts using CNC machined billet aluminum 1-3/8” tie rod clamps (1-5/8” clamps available) and the rod end features FK spherical bearings for precise and reliable operation.

• Through shaft design eliminates the push/pull sensation associated with traditional stabilizers
• 5WT shock oil for consistent suspension damping along a wide temperature range
• FK Rod End bearings for precise function
• Increased steering damping over stock unit
• Provides symmetrical steering feel throughout input range
• 100% bolt-on installation
• Mounts to OE tie rod (1-3/8”)
• Optional clamps for aftermarket heavy duty tie rods (1-5/8”)
• Fully serviceable ICON 2.0 Aluminum Series shock
• 6063 clear anodized aluminum shock body provides excellent corrosion resistance and superb heat dissipation
• 5/8” chrome plated hardened steel shaft

Vehicle Specific

• ICON 18-UP JL/20-UP JT 2.0 CENTERLINE STABILIZER KIT

Attributes:

• Brand Name: ICON Vehicle Dynamics
• GTIN: 00840103401416
• 50: No
• 502: 0.625
• 2327: 2
• 2328: Oil
• 2329: Aluminum
• 3390: Performance
• AAP_UDA_12: EA
• AAP_UDA_22: 1
• AAP_UDA_4: 55
• Add-On Part: 614525 - UNIVERSAL TUBE CLAMP KIT 1.625
• Adjustable Damping: No
• California Prop 65 Warning: Yes
• Color: Light Grey
• Lower Mount Type: Eyelet
• Mounting Bracket Included: yes
• Service Parts: 202006 - 2.0 CENTERLINE STABILIZER REBUILD KIT
• Shaft Material: Chrome
• Steering Stabilizer Configuration: Through-Shaft
• Upper Mount Type: Eyelet

Extended Information:

• Country of Origin: United States
• Emissions : Emissions Compliance Exempt
• Life Cycle Status: Available Only While Supplies Last

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 24.0000 x 7.0000 x 4.0000 inches
• Weight: 7.0000 POUNDS

PDF:
