Motor is IP54 with 65% duty cycle
- 22% more cooling over other designs
- Motor is IP54 with 65% duty cycle
- Cooler Assembly Only
- 200 Micro Extruded passages
- Large surface area to transfer heat for external air flow cooling
- Turbulent oil flow design promotes a more complete cooling
- Large 5/8-inch ports prevents inlet/outlet restriction
- Furnace brazed rails have been tested to 300psi of pressure
- 80-watt, 10-inch, 800 CFM electric fan
- 33,930 BTU/HR and in excess of 30,000 GVW!
Attributes:
-
Brand Name: BD Diesel
-
GTIN: 00990011405072
-
Engine: Motorhome Diesel Power
-
Make: Ford
Extended Information:
-
Country of Origin: CN
-
Emissions : CARB Eligible
-
Life Cycle Status: Available To Order
Packing Information:
-
Quantity of Each: 1
-
Package UOM: EA
-
Dimension: 18 x 15 x 8 inches
-
Weight: 8 POUNDS
