Bilstein Shock Absorbers

Bilstein AS2 (BV) Series shock absorbers feature an aluminum threaded body design with base valve technology to deliver superior grip with lower nitrogen pressures. These 46mm dampers are designed with single adjustable shafts for additional tuning capabilities and can be used with our without coilover hardware. The AS2 (BV) Series offers increased grip and traction in a rebuildable design with multiple tuning options.

• Bilstein AS2 (BV) Series shock absorbers feature an aluminum threaded body design with base valve technology to deliver superior grip with lower nitrogen pressures.
• These 46mm dampers are designed with single adjustable shafts for additional tuning capabilities and can be used with our without coilover hardware
• The AS2 (BV) Series offers increased grip and traction in a rebuildable design with multiple tuning options.

Vehicle Specific

• No Applications

Attributes:

• Brand Name: Bilstein
• GTIN: 00651860948201
• Adjustable Damping: Single Adjustable - Rebound
• Body Design: Threaded Body Screw Top (Coilover)
• Body Material: Aluminum
• Collapsed Length (IN): 16.30
• Collapsed Length (MM): 414.8
• Extended Length (IN): 24.40
• Extended Length (MM): 620.8
• Finish: Clear Anodized
• Internal Design: Monotube
• Lower Mount Type: 1/2in Heim
• PartType: Shocks / Struts
• Piston Diameter: 46mm
• Piston Type: Digressive
• Segment: Motorsports
• Series: AS2-BV Series
• Shaft Diameter: 14mm
• Spring Seat Included: Yes
• Stroke/Travel Length (IN): 8.11
• Stroke/Travel Length (mm): 206.0
• Upper Mount Type: 1/2in Heim
• Valving Identifier: RR ARIZONA

Extended Information:

• Country of Origin: US
• Emissions : 4
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 29.5000 x 3.5000 x 3.5000 inches
• Weight: 7.0000 POUNDS
