The advantage of a rolled tube core is the rounded edge which allows airflow to travel around the tube face and into the intercooler core for maximum airflow and heat dissipation (Compared to the OEM flat face tube which scatters airflow when contacting the tube face). Both the OEM intercoolers and the CSF by PWR upgraded performance intercoolers are designed around 87mm thick cores with 103mm wide side channel end plates. This allows for a true plug-and-play "drop-in fit" installation that requires absolutely no modifications to install, and does not require trimming of the expensive OEM carbon fiber air ducts.
- Heavy duty bar & plate core construction
- All-aluminium cast endtanks
- High-Density internal/external fin design for maximum surface area contact and high-performance cooling efficiency
- "Drop-in" fit requiring no modifications to install.
- Pressure tested at 120 psi for maximum reliability in extreme boost applications
- Precise "Quick-Connect" inlet/outlet connections for a secure "OEM fit" (when applicable)
- CSF's leading high quality thermal rejection powder coating finish
Attributes:
-
Brand Name: CSF Cooling - Racing & High Performance Division
-
GTIN: 00710353081662
-
Color: Raw Billet Aluminum
-
Core Color: Raw Aluminum
-
Core Length: 313mm
-
Core Material: Aluminum
-
Core Row Quantity: 2
-
Core Thickness: 87mm
-
Core Width: 229mm
-
Grade Type: Performance
-
Inlet Fitting Gender: Male
-
Inlet Tank Material: Billet Aluminum
-
Installation Type: Drop-In Fit Installation
-
Mounting Hardware Included: No
-
Outlet Fitting Gender: Male
-
Outlet Type: Quick Connect
-
Type: Air-to-Air
-
Universal Or Specific Fit: Specific
Extended Information:
-
Country of Origin: United States
-
Emissions : Emissions Compliance Exempt
-
Life Cycle Status: Available To Order
Packing Information:
-
Quantity of Each: 1
-
Package UOM: EA
-
Dimension: 24 x 15 x 24 inches
-
Weight: 26 POUNDS
