Fitment Note: The CSF #7231/7231B are based off the early model GT-R Radiator Design (Slim Tank). The radiators fit both the early and late model R34 GT-Rs, but the fan shroud will require different mounting hardware for the late models.
- 2-Row - 42mm Ultra-High-Performance Core
- Individually Leak and Pressure Tested
- OE Location Fan Shroud Mounting Points
- Hand Brushed Satin Finish
- 2-Year Limited Warranty
- 75 Cooling Tubes with CSF's Exclusive B-Tube Technology
- 6.5mm Tall Ultra Efficient Fins with a Multi-Louvered Design for Maximum Surface Area Contact
- CNC Machined Mounting Pins and OEM Style Inlet/Outlet
- 1/8th NPT Temp Sensor Port on Top End Tank
- M16 x 1.5P temperature sensor port with pre-installed plug
- 100% All Aluminum TIG-Welded Construction
- 1.4 Bar High Pressure Radiator Cap with CSF embossed logo
- True Plug-and-Play "Drop-in Fit" Installation Requires Absolutely No Modifications
Attributes:
-
Brand Name: CSF Cooling - Racing & High Performance Division
-
GTIN: 00710353072318
-
ADD-ON: 7231B
-
Coolant Hose Inlet Connection Type: OE Type Connection
-
Coolant Hose Outlet Connection Type: OE Type Connection
-
Core Height: 450mm
-
Core Material: Aluminum
-
Core Row Quantity: 2
-
Core Thickness: 42mm
-
Core Width: 644mm
-
Down Flow Or Cross Flow Type: Down Flow
-
Finish/Color: Satin
-
Frame Included: No
-
Grade Type: Performance
-
Inlet Connector Type: Slip On
-
Inlet Diameter: 35mm
-
Inlet Location: Top Right
-
Installation Type: Drop-In Fit Installation
-
Internal Engine Oil Cooler: No
-
Internal Transmission Oil Cooler: No
-
Mounting Hardware Included: No
-
Mounting Type: Mounts with OE Hardware
-
Outlet Connector Type: Slip On
-
Outlet Diameter: 35mm
-
Outlet Location: Bottom Right
-
Radiator Cap Included: Yes
-
Tank Material: Aluminum
-
Thermostat Included: No
Extended Information:
-
Country of Origin: ID
-
Emissions : Emissions Compliance Exempt
-
Life Cycle Status: Available To Order
Packing Information:
-
Quantity of Each: 1
-
Package UOM: EA
-
Dimension: 30 x 25 x 6 inches
-
Weight: 18 POUNDS
